11
Fig. 14 Connect peel-off sensor cable to main board
Fig. 15 Peel-off sensor cable inst
allation
7.
Insert the peel-off tenons into the lowe
r inner cover mortises until tenons snap
into places.
Fig. 16 Peel-off p
anel inst
allation (I)
8.
Arrange the lower inner cove
r back to the lower cover
.
Roller
T
enon
Mortise
Lower Inner Cover
Lower Cover
Bezel
Mortise
15
17
