6–6 Series 3080 Electrostatic Classifiers
Figure 6-3
Cleaning/Replacing Model 3081 Dacron Screen
Cleaning the Nano DMA Electrodes
WARNING
High voltage is accessible in several locations within this instrument.
Make sure you unplug the power source to the Classifier and unplug the
high-voltage cable from the Classifier to the DMA before disassembling
the DMA or performing maintenance procedures.
To clean the inner rod and inside of the outer tube, follow these
steps and refer to
284HFigure 6-4:
1. Switch the Classifier off and unplug the power cord.
