Operation 3-3
Main Tab
The Main tab is the default screen. The left side of the screen
summarizes the concentrations for the currently selected location. Tap on
the size and count portion of the screen to enable Zoomed Data Screen
(see Setup Tab).
The display shows:
• Temperature
*
• Relative humidity*
• Bin sizes
• Particle count/concentration
The status bar at the top of the screen shows the current time and date
(see the Setup Tab) and indicates:
Instrument status error. If this icon is shown, it can be pressed and
a more detailed description of the operational error will be shown.
Refer to the troubleshooting section for appropriate actions. If an
instrument error occurs, an audible alarm will also sound.
Sufficient flow through the instrument.
During Start Delay (Delay) and Hold Times (Hold), this is only
an indicator of flow On. During Sample Time (Time), this is an
indicator of flow within specified tolerances.
Insufficient flow through the instrument. If this icon is shown, it
can be pressed and a more detailed description of the flow error
will be shown. Refer to the trouble shooting section for
appropriate actions.
If a flow error occurs, an audible alarm will also sound.
During Start Delay (Delay) and Hold Times (Hold), this is an
indicator of flow Off. During Sample Time (Time), this is an
indicator of flow not being within specified tolerances.
Operating on AC power, no battery installed
Operating on AC power, battery is installed and charging. (The
battery charges when the instrument is on but not actively taking a
particle sample.)
*
Temperature and Humidity are displayed only if the optional T/H probe is installed.
