3-34 AeroTrak
®
Handheld Airborne Particle Counter
4. To select data for export by zone, move a desired zone to the box on
the right to select it. To select data by sample index range instead,
tap the Select by Record button at the bottom.
5. To select data for export by range of sample Index, tap Select Range
radio button and then select the lower and upper sample index
numbers. To select data for export by zone instead, tap the
Select by Zone button at the bottom.
6. Once the records or the Zones have been selected, press Export…
to begin exporting. Status screens allow viewing the progress of
the export.
C A U T I O N
DO NOT remove the external drive during the export process. If the
thumb drive is removed, re-insert and restart the download process.
Data stored on the instrument is not lost during the transfer.
