Wiring the Alarm
System specifications:
• Maximum voltage: 15 VDC (DO NOT USE AC POWER)
• Maximum current: 1 Amp
• Correct polarity must be observed (see pin-outs above)
• The alarm switch, located inside the D
USTTRAK™ monitor must be
located on the ground side of the alarm system.
!
WARNING
The DUSTTRAK™ monitor Alarm Output function should not be
used to detect hazardous conditions or to provide an alarm for
protecting human life, health or safety.
!
Caution
The alarm switch must not be wired to AC power! Failure to
properly install the user alarm could damage the DUSTTRAK™
instrument and/or void the instrument warranty! Please read and
follow all instructions before wiring or operating the user alarm.
