TSI Instruments SidePak AM520 - Power Port; Exhaust Port; Inlet

Chapter 3
14
Power Port
Connect the power supply to
this port to charge the TSI
®
battery pack or to power the
instrument at any time.
NOTICE
Many power supplies look
alike. Use the proper power
supply to prevent damage.
NOTICE
After charging the battery, close/seal the AC power port with the
attached AC dust plug.
Exhaust Port
Air drawn though the
instrument exits here.
Inlet
Interchangeable inlet.
Install the standard
inlet or one of four
impactors provided
with SidePak™
AM520/AM520i Kits.
