Tulikivi HALLA E - Circuit Board Connectors

ENG
23
Temperature sensor
Thermocouple
Touch Screen
Switch start
Door switch reset
Door switch
KNX bus
12 V dc yellow
IN green or blue
5 V dc white
A in brown or red
ON/OFF
GND
RESET
GND
DOOR
GND
12 V white
GND brown
Touch Screen
B yellow
A green
NEG red
POS yellow
BUS -
BUS+
CIRCUIT BOARD CONNECTORS
Place for the KNX module relay card
FIGURE 4
Heating
alternation
