TurboChef TORNADO Service Manual

ITEM DESCRIPTION
PART NUMBER FIGURE NUMBER (PAGES 65-78)
Fan Blade, Motor NGC-3007 38
Fan, Magnetron Cooling 100083 20
Filter, EMI, 1Ph (USA, Europe, Latin America, Japan) 100543 None
Filter, EMI, 3Ph (Europe, Asia-Pacific, Korea, Japan) 100545 None
Fuse, F1, 12 Amp 100592 38
Fuse, F2, 12 Amp 100592 38
Fuse, F3, 20 Amp 100599 20
Gasket, Convection Heater NGC-1043 38
Gauge, Door Switch (Adjustment Tool) NGC-1215 32
Grease, Food Grade, USDA H-1 NGC-3006 30
Guard, TurboChef Oven, Domestic 103181 None
Guard, TurboChef Oven, International 103381 None
Handle, Door, Standard 102750 35
Handle, Door, SBK NGC-1216 None
Harness, Line Voltage (Europe, Asia-Pacific, Japan) NGC-1150-3 None
Harness, Line Voltage (North America) NGC-1150-1 None
Harness, Line Voltage (UK, Ireland, Brazil) NGC-1150-2 None
Harness, Low Voltage, Old Switch Setup 100185 None
Harness, Low Voltage, New Switch Setup NGC-1418 None
Heater Element, IR NGC-3003 39
Heater, Convection NGC-3011 38
Hinge, Left 102805 26
Hinge, Right 102804 26, 31, 33, 34
Insulation, Door, 1 NGC-1125-1 35
Insulation, Door, 2 NGC-1125-2 35
Insulator, Adhesive NGC-1163 21
Keypad, OUT NGC-1110-4 17
Keypad, Standard NGC-1110-1 17
Keypad, SBK NGC-1110-3 17
Keypad, SWY NGC-1110-2 17
Label, Caution, Empty Cavity NGC-1165 35
Label, Caution, Hot NGC-1148 46, 47
Label, Precaution for Safe Use NGC-1138 35
Label, Schematic (Europe, Asia-Pacific, 230 VAC) NGC-1176-4 46, 47
Label, Schematic (Europe, Asia-Pacific, 400 VAC) NGC-1176-3 46, 47
Label, Schematic (USA) NGC-1176-1 46, 47
Label, Schematic (UK, Ireland) NGC-1176-2 46, 47
Label, Schematic, Standard (Latin America) NGC-2020 46
Label, Schematic, SBK (Latin America) NGC-2011-8 47
Label,
Service Assistance
NGC-1177 46, 47
Label,
Service Number
NGC-1170 35
Latch, Bracket NGC-1072 30
Latch, Spring Door NGC-1087 30
Leg, 4”, Black Plastic 100785 46
Leg, 4”, Standard, Stainless Steel 100781 46
Leg, 4”, SBK 100784 47
Leg, 7”, SBK Kit (4 legs) NGC-3068 47
Magnetron NGC-3015 20, 21
Motor Controller 100443 38
Nameplate, TurboChef NGC-1155 35
Nut, Crescent, Keps, Hex, #8-32, External Tooth 102692 46, 47
80
COMPREHENSIVE PART LIST
