TurboChef TORNADO Service Manual

ITEM DESCRIPTION
PART NUMBER FIGURE NUMBER (PAGES 65-78)
Nut, Flange, 1/4-20 100906 38
Nut, M5, Yellow Zinc (Magnetrons, Bottom Electrical Plate) 100101 None
Nut, Push, 1/8 101293 35
Nut, Stainless, #4-40 102960 17
Pad, Abrasive, Non-Slip NGC-1187 46, 47
Pin, Clevis, 3/16 Diameter x 1” Long 101119 30
Plate, Door Switch NGC-1126 30, 31, 33, 34
Plug, Hole, Black, 1/2” Diameter 101191 46, 47
Rack, Raised NGC-3064 46, 47
Rack, Recessed NGC-1274 46
Rack,
Standard
NGC-1064-1 46
Reader, Smart Card 100506 17
Relay, K1, Filament Transformers 101273 20
Relay, K2, HV Transformers 101273 20
Relay, K3, Monitor 101273 20
Relay, K4/K5, Solid State, Convection Heater/IR Element NGC-3005 38
Relay, K6, 208/240 Transformer Taps (USA
only)
101272 None
Relay, K7, Magnetron Fan, DNK NGC-3030-11 None
Relay, K7, Magnetron Fan, OXXO NGC-3030-5 None
Relay, K7, Magnetron Fan, SBK (USA) NGC-3030-3 20
Relay, K7, Magnetron Fan, SBK (Europe, Asia-Pacific MPh) NGC-3030-15 20
Relay, K7, Magnetron Fan, SBK (Europe SPh) NGC-3030-13 20
Relay, K7, Magnetron Fan, SBK (Indiana/North Carolina) NGC-3030-14 20
Relay, K7, Magnetron Fan, Standard (USA) NGC-3030-1 20
Relay, K7, Magnetron Fan, Standard (Europe, Asia-Pacific MPh) NGC-3030-4 20
Relay, K7, Magnetron Fan, Standard (Europe SPh) NGC-3030-7 20
Relay, K7, Magnetron Fan, Standard (Latin America) NGC-3030-12 20
Relay, K7, Magnetron Fan, SWY (USA) NGC-3030-2 20
Relay, K7, Magnetron Fan, SWY (Europe, Asia-Pacific MPh) NGC-3030-9 20
Relay, K7, Magnetron Fan, SWY (Europe, Latin America SPh) NGC-3030-6 20
Relay, K7, Magnetron Fan, TESCO NGC-3030-10 None
Relay, K7, Magnetron Fan, WAWA NGC-3030-8 None
Ring, E-clip 101296 30
Ring, Snap 101312 39
Screw, #4-40 x 5/8 102902 31
Screw, #4-40 x 3/4 101555 32
Screw, #4-40 x 1 1/8 101558 33, 34
Screw, #4-40 x 1 1/4 101557 29, 30
Screw, #6, Sheet Metal 100684 21
Screw, #8, Crescent, TRHD, Serrated Phillips 101688 35, 38, 39, 46
Screw, #8, Crescent, TRHD, Serrated Phillips, Black Oxide 101691 47
Screw, #8-16, Torx Security 102752 46
Screw, #8-16 x 1/2, Torx Security, Black Oxide 102756 47
Screw, #8-18, SS 101701 22
Screw, #8-32 x 3/8 102921 29, 30, 31, 32, 33, 34, 46
Screw, #8-32 x 3/8, PFH, CSK 102809 22, 26, 29, 32, 35
Screw, #8-32 x 3/8, PPHD, SEM, SS, Internal Tooth 102922 47
Screw, #8-32 x 3/8, Torx Security 102748 35
Screw, #8-32 x 1/2, Cap 101666 22
Screw, #10-32 x 1/2, SS, Hex 101381 26
Shield, Microwave NGC-1116 39
COMPREHENSIVE PART LIST
81
