3.6 NAME OF THE COMPONENTS
FIG.06 shows and names the components that make up the machine in the most complete version EMF.
5
4
16
6
17
10
11
12
13
14 15
9
7
8
1
3
2
FIG.06
KEY:
1) Bodywork
2) Electric vibrator
3) Vibrating sieve
4) Hopper
5) Mixer device
6) Mixer
