Turbosol UNI 30 E - 3 Technical Description; Name of Machine

EN
UNI 30 E 17261 - 561.228 3 - TECHNICAL DESCRIPTION
Cap. 3 - Pag. 1/5
THIS MANUAL IS PROPERTY OF - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
3.1 NAME OF MACHINE
CE mark plate
1
2
3
kg
FIG.03
(1) = Machine series:
(2) = Machine model:
(3) = Machine serial number.
Position of the CE mark plate
The CE mark plate (FIG. 04-REF. 1) is affixed to the machine's bodywork.
Position of the machine serial number.
The machine's serial number (FIG.05-REF.1) is punched onto the machine frame and onto the body of the reducer inside the
bodywork.
