UNI 30 E 17261 - 561.228 8 - MAINTENANCE
8
- Pag. 2/6
THIS MANUAL IS PROPERTY OF - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
Cap.
1
2
1
FIG.50 FIG.51
• Check and clean the compressor air filter.
Check and clean the filter (FIG.50-REF.1 positioned inside the protective lid using compressed air.
• Check mixer reducer oil
To check the mixer reducer oil level, open the cap above the reducer. If necessary, top up using ELF REDUCTELF SP220 oil
or equivalent.
At the end of a work session
Grease:
the by-pass lever (FIG.52-REF.1) mixing device support (FIG.52-REF.4), the belt-tensioner arm (FIG.52-REF.3) and the
reducer (FIG.52-REF.2).
Do not exaggerate with greasing the reducer (FIG.52-REF.2) as problems could occur.
