turck CODESYS 3 User Manual

37
2017/06
 Configure the in- and output data lengths which have to be exchanged with the higher-level
PROFINET Master. Therefore add the respective process data entries.
Fig. 31: Configuring the PROFINET Device
NOTE
Please observe the following for the configuration of the I/O data:
The CODESYS input data have to be have to be configured as output data in the PROFINET
Controller configuration, the CODESYS output data have to be configured as input data.
The data thus have to be configured in reverse order in the PROFINET Controller configu-
ration (see also Configuring the in- and output data (page 41)).
