24
To ensure that the Ph and Rf modules are parallel, make certain that the measurements in the figure below are not
exceeded.
Close the Ph photocell module using the PH2 cross-head screwdriver.
Close the Rf reflector module using the a PH2 cross-head screwdriver.
D
UW
+241 ± 20mm
D
±
2
0
m
m
UW
[ACCESSORY]
Stabilizing plates
In case of removable applications, these plates maintain the archway stability and, acting as an adapter, allow the
archway to be easily relocated. In order to prevent the archway from tipping over in case of bumps, the stable
anchoring to the ground is anyway mandatory
.
Metal version
Attaching the plates to the archway
Anchor the archway to the plates by fully tightening
screws vp.
Plastic version (especially suitable for uneven floor)
Attaching the plates to the archway
Anchor the archway to the plates by fully tightening
knobs k.
k
k
800 (31.5 “)
700 (27.56 “)
73 (2.87“)
225 (8.86“)
15 (0.59”)
640 (25.20 “)
ø11.5 (0.45 “)
Ph
TX
4
8
0
m
m
(
1
8
.
9
”
)
2
1
5
m
m
(
8
.
5
”
)
8mm (0.3”)
øM8
vp
vp
