EXTERNAL CONNECTION OF THE 3870EHS AUTOCLAVES
ELECTRONICS BOX
Valves & Solenoids drivers
Digital Input & Electrodes
Chamber temperature sensor
PC Communication Port
Test Points Connector
Jacket Pressure sensor
Chamber Pressure sensor
Pressure switch & Low Float of
Vacuum Pum
p
Reservoir
Cut Off Switch Connection
Heater Elements AC Control
Power Inlet 220VAC/60Hz
Vacuum Pump AC Control
&Water Pum
p
AC
