96
Corrections
17.1 Unplug and replug in the connector
making sure good contact is made
17.2 Fix the connections
17.3 Replace the pressure sensor and calibrate
(see para 5).
17.4 Replace the ANL-T2 and calibrate (see
para 5).
18.1 Unplug and replug in the connector
making sure good contact is made
18.2 Calibrate the system (see para 5)
18.3 Clean or replace the pressure sensor and
calibrate (see para 5).
18.4 Replace the ANL-T2 and calibrate (see
para 5).
19.1 Fix the connections.
19.2 Replace the electrode
19.3 Clean the electrode with alcohol and
check that the quality of the water used
in the jacket is as specified in the
manual.
19.4 Replace ANL- T2 board.
Possible cause check-up and tests
17.1 Check that the connector of the sensor is
properly plugged into JP1 on the ANL-
T2 board.
17.2 Check that the wires and connector are in
good condition.
17.3 The pressure sensor is defective.
17.4 The pressure measuring circuit on ANL-
T2 board is defective.
18.1 Check that the connector of the sensor is
properly plugged into JP1 on the ANL-
T2 board.
18.2 The system is out of calibration
18.3 The pressure sensor is contaminated with
dirt or is defective.
18.4 The pressure measuring circuit on ANL-
T2 board is defective.
19.1 Check if the wire connected to the
electrode is shorted to ground.
19.2 Check if the electrode is shorted to
ground.
19.3 The electrode is dirty.
19.4 If there is no short to ground then the
ANL-T2 board is bad.
10. TROUBLESHOOTING (cont.)
10.4 In Process Malfunction (cont.)
Symptom
17. The displayed pressure of
the chamber permanently
indicates a pressure less
than 7.3 psi.
18. The displayed pressure is
significantly different from
the actual pressure.
19. The electrode senses water
in the jacket, but the jacket
is empty.
