85
Preset store 227 Set to 1 to store – automatically resets to 0.
Preset erase 228 Set to 1 to erase – automatically resets to 0.
Adjust outputs
Output enable 170 0=Blanked, 1=Active
Lock source (connector) 149 0x10 to 0x1F = RGB1 to RGB16
0x30 to 0x3F = CV1 to CV16
0x40 to 0x4F = YC1 to YC16
0x50 to 0x5F = SDI1 to SDI16
0xD0 = OUT1, 0xD1 = OUT2
0xF0 = TC1, 0xF1 = TC2
Lock method 10A 0 = Off
1 = Genlock
2 = Lock & Mix
3 = DARSlock (some units only)
4 = Frm.lock (some units only)
Lock H Shift 14A -4096..4096
Lock V Shift 14B -4096..4096
Output resolution 083 1..1000
Output image type See Adjust resolutions entries
Output image type digital 16C 0 = RGBHV
3 = YUV
9 = Not available
HDCP required 233 0..1, Off, On (if display supports it)
HDCP status 234 0=Unavailable
1=Supported
2=Active
3=Repeater supported
4=Repeater active
5=No display
(Other values indicate various HDCP
authentication states.)
Background Y 13B 16..235
Background U 13C 16..240
Background V 13D 16..240
SDI optimization 197 0..1, Off, On
Output Standard 101 0 = NTSC/PAL, 1 = PAL-M/PAL-N, 2 =
SECAM
Output CV/YC IRE 133 -7.5..12.5
Output CV/YC Hue
(degrees)
139 -22..22
Output SC/H Phase 085 -180..180
Output Luma Bandwidth 134 0,1,2 = Low, Medium, High
Output Chroma
Bandwidth
135 0,1,2 = Low, Medium, High
Output Chroma delay 137 -4..3
PAL WSS 130 0 = Off
1 = 4:3 Full format
2 = 14:9 Letterbox centre
