86
3 = 14:9 Letterbox top
4 = 16:9 Letterbox centre
5 = 16:9 Letterbox top
6 = >16:9 Letterbox centre
7 = 14:9 Full format
8 = 16:9 Full format
Take 11E 0->1 = Perform a Preview -> Program
transition
Audio amp. Volume 201 -16 to 15
AES/SDI Chan. 1 source 20B
AES/SDI Chan. 2 source 20C
AES/SDI Chan. 3 source 20D
AES/SDI Chan. 4 source 20E
AES/SDI Chan. 5 source 20F
AES/SDI Chan. 6 source 210
AES/SDI Chan. 7 source 211
AES/SDI Chan. 8 source 212
0x00 to 0x07 = SDI1-1 to SD1-8
0x08 to 0x0F = SDI2-1 to SDI2=8
0x10 to 0x1F = AES1 to AES16
0x20 = AFV (audio follow video)
Adjust windows
Program source / Window
source (connector)
082 0x10 to 0x1F = RGB1 to RGB16
(Also includes DVI / YUV sources)
0x30 to 0x3F = CV1 to CV16
0x40 to 0x4F = YC1 to YC16
0x50 to 0x5F = SDI1 to SDI16
0xD0 = OUT1, 0xD1 = OUT2
0xF0 = TC1, 0xF1 = TC2
Select Universal source 241 0xE0 to 0xEF select universal inputs 1 to 16
Source resolution 0F8 Read only – returns # of resolution
Window Enable 12B 0..1 = Off, On
Zoom level % 086 100..1000
Zoom level H % 103 100..1000 (only used in Advanced A/R
mode)
Zoom level V % 105 100..1000 (only used in Advanced A/R
mode)
Aspect ratio in 107 0.1:1..9.99:1 (read only)
H/V zoom pan % (H) 09F 0..100
H/V zoom pan % (V) 0A0 0..100
Image freeze 09C 0..1 = Off, On
H/V crop % (H) 223 0..100
H/V crop % (V) 224 0..100
H/V out shift (H) 0AD -4096..4096
H/V out shift (V) 0AE -4096..4096
Shrink level % 087 10..100
Shrink level H % 104 10..100 (only used in Advanced A/R mode)
Shrink level V % 106 10..100 (only used in Advanced A/R mode)
Shrink enable 18E 0..1 = Off, On
H/V shr. pos.% (H) 0DA 0..100
H/V shr. pos.% (V) 0DB 0..100
