88
E.blnd size V 18C 0.. limited by V height
E.blnd gamma H 188 1..150 1=0.01, 150=1.50
E.blnd gamma V 18D 1..150 1=0.01, 150=1.50
E.blnd comp cent 198 0..99
E.blnd comp side 19D 0..99
Logos (on certain models only)
Logo enable 12B 0..1 = Off, On
Logo number 143 0..9 Logo selection
H/V out shift (H) 0AD 0..100 %
H/V out shift (V) 0AE 0..100 %
Max fade level 10F 0..100%
Layer priority 144 0..5
Borders (on certain models only)
Border enable 150 0..1 = Off, On
Border H size 152 0..99
Border V size 151 0..99
Border H offset 153 0..99
Border V offset 154 0..99
Border Opacity 158 0 (fully transparent) ..100 (solid)
Border Y 155 16..235
Border U 156 16..240
Border V 157 16..240
Adjust sources
Source to adjust.
This only changes what’s
shown in the menu – use
the CHA values below to
change settings of a
source.
CHA 116 0x10 to 0x1F = RGB1 to RGB16
0x30 to 0x3F = CV1 to CV16
0x40 to 0x4F = YC1 to YC16
0x50 to 0x5F = SDI1 to SDI16
0xD0 = OUT1, 0xD1 = OUT2
0xF0 = TC1, 0xF1 = TC2
Still Image / Testcard F0..F1 0DC 0..10
Autoset 10..1F 0FE 1= Start Autoset procedure
Aspect correct 10..5F 240 0=Fill (default)
1=Aspect, 2=H-fit, 3=V-fit, 4=1:1
UMD display address 10..5F 263 0 to 126, as per TSL 3.1 protocol
Label font 10..5F 246 0..15 to select different fonts
Label background color 10..5F 247
Label foreground color 10..5F 248
0=Black 8=Transparent
1=Blue 9=Grey
2=Green 10=Opaque Black
3=Cyan 11=Opaque White
4=Red 12=Flashing Blue
5=Magenta 13=Flashing Green
6=Yellow 14=Flashing Red
7=White 15=Flashing White
Label H. Size 10..5F 249 0..8
Label V. Size 10..5F 24A 0..8
