89
Label H. Position 10..5F 24D 0..3 (Off / Left / Center / Right)
Label V. Position 10..5F 24E 0..3 (Off / Top / Middle / Bottom)
Label char. to adj. 10..5F 24B 0..23
Label char. value 10..5F 24C 32..127
EDID to use 10..1F 243 0..7 to specify EDID entries 1..Mon
EDID capture entry# 10..1F 244 0..7 to specify EDID entries 1..Mon
EDID capture Grab 10..1F 245 Set to 1 to Grab. Auto-resets to 0.
HDCP advertise (DVI) 10..1F 237 0=Off, 1=On
HDCP status (DVI) 10..1F 238 0=Inactive, 1=Active
TL pos. adj. (left) 10..FF 0B6 -100..100
TL pos. adj. (top) 10..FF 0B7 -100..100
BR size adj. (right) 10..5F 0DE -100..100
BR size adj. (bottom) 10..5F 0DF -100..100
Audio input source
(internal)
10..FF 242 0..4
Selects inputs 1 to 4 + Mute.
OPTION audio input 10..FF 0D0 0..9 = Channels 1 .. 10 on A2-2000
Audio vol 10..FF 0CF -16..15 (-16=Mute)
Bal 10..FF 0D1 -15..15
On source loss
(was Deglitch)
10..5F 0A3 0=Show, 1=Freeze, 2=Blue, 3=Black,
4=Remove
Source stable (read only) 22A 0=Unstable, 1=Stable
Input pixel phase 10..5F 091 0..31
RGB input type 10..1F 0C1 8 = Auto
6 = D-RGB
11 = D-YUV
10 = A-RGB
12 = A-YUV
For universal HD15 inputs:
5 = CV/YC
For units with DVI-U inputs:
13 = CV (or A-CV)
14 = YC (or A-YC)
For units with DVI-U 5x BNC breakouts:
15 = B-RGB
16 = B-YUV
17 = B-CV
18 = B-YC
RGB contr. (red) 10..1F 0C5 75..150
RGB contr. (green) 10..1F 0C6 75..150
RGB contr. (blue) 10..1F 0C7 75..150
YUV setup level 10..1F 23E 0=0 IRE, 1=7.5 IRE
De-int. 10..FF 0B8 0..6 = Normal, Auto, Film 3:2, M.comp.low,
M.comp.med., M.comp.high, Frame/bob
(Film mode detected) 10..FF 0E3 0..1 = Not detected, Detected
Diagonal interpolation 10..FF 22B 0..1 = Off, On
