36
FHD Hight Bright Field Monitor
07 OTHER FUNCTIONS
[11] INTERNAL PATTERN
<Color Bar + Pluge Pattern> <Gray Pattern>
• Displays internally generated test patterns.
- The pattern consists of Color Bar + Pluge pattern and Grayscale patterns.
Full screen colors of various gray levels (0~100%) are also embedded.
