TVLogic LVM-075A User Manual

8 Multi Format LCD Monitor
3. Controls & Functions
LVM-176W : FRONT
● [OPERATE] Lamp
- Indicates the status of power connection and
monitor operation.
- The LED is o with power o.
- The LED is red when the monitor is in waiting
mode with power on.
- The LED is green when the monitor is
operating.
● [POWER] Button/Lamp
- Turns on or o the monitor power.
● [ANALOG] Button/Lamp
- Used to select desired Analog input.
- Press the button to activate the analog
input menu-selection, then use UP
and DOWN button to select desired input.
* Please refer to “7. Button Functions [1]
ANALOG Button” for more information.
● [DIGITAL] Button/Lamp
- Used to select desired Digital input. (HDMI,
DVI Digital)
- Press the Digital Button to activate the
Digital input menu-selection, then use the
Knob to select desired input.
*
Please refer to “7. Button Functions [2]
DIGITAL” for more information.
● [SDI-A] Button/Lamp
- Used to select SDI-A input.
● [SDI-B] Button/Lamp
- Used to select SDI-B input.
● [SCAN] Button/Lamp
- Used to change the scan mode. Press the
button to activate through the scan modes:
OVER SCAN > ZERO SCAN > UNDER SCAN >
1:1 SCAN > FIT WIDTH
*
Please refer to “8. Other Functions [1]SCAN”
for more information.
● [ASPECT] Button/Lamp
- Used to change the display ratio between
4:3 and 16:9.
- Activates in the order of [16:9]-[4:3]-[2.35:1]-
[1.85:1]-[15:9]-[16:10] -[AUTO]-[16:9].
● [MARKER] Button/Lamp
- Used to activate/deactivate the Marker.
- The Marker is normally displayed when you
select Aspect ratio you want in OSD Menu.
● [H/V DELAY] Button/Lamp
- Used to check horizontal sync. and vertical
sync. simultaneously.
● [BLUE ONLY/MONO] Button/Lamp
- Press the button to remove red and green
from the input signal and display the screen
only under a blue signal. Press the button
again to activate mono mode.
- This function is not activated in the RGB, DVI
ANALOG, DVI DIGITAL, HDMI modes.
● [PHASE] Button/Lamp
- Activates in the order of CHROMA, PHASE,
Closed Caption, while OSD menu is not
activated, and you can toggle through the
values by UP/DOWN keys. Toggling order is
as below depending on input signal.
- SDI-A/B modes : CHROMA > Closed Caption.
- Component mode : CHROMA.
- Composite/S-Video modes : CHROMA >
PHASE > Closed Caption.
- DVI-Analog mode : PHASE.(AUTO PHASE)
● [WAVE FORM] Button/Lamp
- Activates Waveform or Vector scope of input
signal.
- Operating change order is WAVE FORM
> VECTOR SCOPE > WAVE FORM WIDE >
WAVE FORM YCbCr > WAVE_VECTOR > FULL
WAVEFORM(Y) > FULL VECTORSCOPE.
*
Please refer to “8. Other Functions [3]
WAVEFORM” for more information.
