TVLogic LVM-075A User Manual

Multi Format LCD Monitor 9
3. Controls & Functions
LVM-176W : FRONT
● [MENU] Button/Lamp
- Activates OSD menu.
● [DOWN] Button/Lamp
- Used to move the cursor down while OSD
menu is activated and to decrease the value
of the selected feature.
● [UP] Button/Lamp
- Used to move the cursor up while OSD menu
is activated and to increased the value of the
selected feature.
● [ENTER] Button/Lamp
- Used to conrm a chosen value.
- Volume window is activated when OSD
menu is not activated. You can adjust the
volume value with UP/DOWN keys.
- Used to move the picture position in
order in 1:1 SCAN mode, when a original
image is bigger than resolution. Please refer
to “8. Other functions [1]SCAN mode” for
more information.
● [APERTURE] Knob
- Used to adjust the picture sharpness. The
value is selectable between 0~24.
- It is not available in DVI ANALOG.
● [BRIGHT] Knob
- Used to adjust the degree of brightness. The
value is selectable between -100~100.
● [CHROMA] Knob
- Used to adjust the saturation of the image.
The value is selectable between -50~50.
- It is not available in RGB, DVI ANALOG, DVI
DIGITAL, HDMI.
● [CONTRAST] Knob
- Used to adjust the contrast. The value is
selectable between -100~100.
● [VOLUME] Knob
- Used to adjust the volume for internal
speaker and external output. The value is
selectable between 0~30.
● [TALLY] Lamp
- Tally lamp that can be toggled in green or
red using the REMOTE(RJ-45) port.
