TVLogic TSM-232W User Manual

10 TVLogic Security Monitor
3. Controls & Functions
TSM-182/232W : REAR
● ~ AC IN
- 100 ~ 240V AC 50/60Hz
● POWER SWITCH
<WARNING!!>>
When using the product make sure to ground,
whenever possible, before connecting the
input signal cable in order to prevent any
possible damage to the product or connected
devices. The damage may include signal noise,
malfunction of main board or display panel.
And the connected devices such as camera or
video source player may also be inuenced
through signal cable. Please check if the AC
power source and the power extender or
power distributor is grounded.
● [CVBS] IN (BNC)
- Signal input terminal for COMPOSITE signal.
● [CVBS] OUT (BNC)
- Signal output terminal for COMPOSITE
input signal through CVBS IN.
● [HDMI(HDCP)] (HDMI)
- Signal input terminal for HDMI signal.
● [DVI-I] (DVI-I)
- Signal input terminal for DVI ANALOG or DVI
DIGITAL signal.
● [SDI-IN A] (BNC)
- Signal input terminal for 3G/HD/SD SDI
signal.
● [SDI-OUT] (BNC)
- Signal output terminal for 3G/HD/SD SDI
input signal through SDI-IN.
● [Audio in] (PHONE JACK)
- Inputs external audio.
● [REMOTE] (RJ-45)
- Provides connection to control equipment
for external monitor control.
- Features can be changed in the [REMOTE]
section of OSD menu.
● [RS422 IN/OUT] (RJ-45)
- Controls the monitor by a protocol provided
by TVLogic or supports TSL protocol.
