TVLogic Security Monitor 9
● [SOURCE] Button/Lamp
- Selects PIP input. (SDI, HDMI, DVI Digital, DVI
Analog, CVBS)
- When you press [SOURCE], OSD menu comes
up, and you can select by knob or UP/DOWN/
ENTER.
● [PBP] Button/Lamp
- Activates PBP(PICTURE BY PICTURE) function.
- It supports PBP ASPECT and PBP FULL, two
aspect ratios.
● [PIP] Button/Lamp
- Activates PIP(PICTURE IN PICTURE) function.
It supports PIP SMALL and PIP LARGE, two
size PIP images.
● [POSITION] Button/Lamp
- Used to change PIP image position.
- It supports BOTTOM-LEFT, BOTTOM-RIGHT,
TOP-LEFT, TOP-RIGHT, four positions.
● [SWAP] Button/Lamp
- Used to change main picture and PIP/PBP
picture when PIP or PBP mode is activated.
● [INFO.] Button/Lamp
- Shows current monitor status.
3. Controls & Functions
TSM-182W / 232W : FRONT
● [MENU/EXIT] Button/Lamp
- Activates OSD menu.
● [ENTER/UP/DOWN] Knob
- Used to move the cursor when OSD menu
is activated and increase and decrease the
selected value.
- Used to select items in OSD menu by
pressing.
- When OSD menu is not activated, if you
press it, following functions are activated
in order of [Volume]-[Bright]-[Contrast]-
[Chroma]-[Aperture].
● [POWER] Button/Lamp
- Turns on or o the monitor power.
● [OPERATE] Lamp
- Indicates the status of power connection and
monitor operation.
- The LED is o with power o.
- The LED is red when the monitor is in waiting
mode with power on.
- The LED is green when the monitor is
operating.
● [AUDIO OUT] (PHONE JACK)
- Outputs dis-embedded audio signal, HDMI
audio signal or stereo signal from outside
through internal speaker or phone jack.
● [USB]
- Used to rmware-update with USB memory
stick(Thumb drive) or color-calibrate the
monitor connecting PC.
● [SPEAKER]
- Used to output Embedded Audio or external
audio.
