TVLogic TSM-232W User Manual

8 TVLogic Security Monitor
3. Controls & Functions
TSM-182W / 232W : FRONT
● [TALLY] Lamp
- Tally lamp that can be toggled in green or
red using the REMOTE(RJ-45) port.
● [PIP INPUT] Lamp
- Shows Input source of PIP & PBP MODE.
● [OPERATE] Lamp
- Indicates the status of power connection and
monitor operation.
- The LED is o with power o.
- The LED is red when the monitor is in waiting
mode with power on.
- The LED is green when the monitor is
operating.
- The LED is orange blinking when the
monitor operating without input signal.
● [CVBS] Button/Lamp
- Used to select MAIN signal.
● [DIV-I] Button/Lamp
- Used to select MAIN signal.
● [HDMI] Button/Lamp
- Used to select MAIN signal.
● [SDI] Button/Lamp
- Used to select MAIN signal.
● [SCAN] Button/Lamp
- Used to change the scan mode. Press the
button to activate through the scan modes:
OVER SCAN > USER ASPECT > ZERO SCAN >
UNDER SCAN > 1:1 SCAN > FIT WIDTH
* Please refer to “8. Other Functions [3]SCAN”
for more information.
#[USER ASPECT] : The user can adjust picture
size by adjusting Width and Height.
● [ASPECT] Button/Lamp
- Used to change the display ratio in order
of [16:9]-[4:3]-[2.35:1]-[1.85:1]-[15:9]- [16:10]-
[AUTO]-[16:9].
● [ZOOM] Button/Lamp
- Used to zoom-in in various ratio.
- After pressing [ZOOM], you can zoon-in the
ratio you want by turning the knob, also
scroll the position you want.
● [FREEZE] Button/Lamp
- Shows pause image for MAIN INPUT SOURCE.
● [C.TEMP] Button/Lamp
- Used to change color temperature in order of
3200K -> 5600K -> 6500K -> 9300K -> User 1
-> User 2 -> User 3
