Dimensions
DimensionsDimensions
Dimensions
A Right edge of black mark 15 or more
B Left edge of black mark 0 to 1.5
C Black mark height 5
D Cut position in black mark 2.5
E Top margin 6.5 / 12
F Black mark pitch 30 to 300
G Bottom margin 9
5.3 Manual Setting of Memory Switch
5.3 Manual Setting of Memory Switch5.3 Manual Setting of Memory Switch
5.3 Manual Setting of Memory Switch
Memory switches can be set manually or by a command.
For manual setting, refer to the next page.
The function of each memory switch is shown in the following table.
(The white-on-black characters are factory setting.)
Notes:
*1: The factory setting of "Paper Select" will be different, depending on the model classfication.
*2: In the case of selecting the thermal roll with the SW4-4, the SW4-5 will not be available. The
SW4-5 will be set to "Black Mark" status for the Black Mark version printer.
*3: In the label mode (with memory switches SW4-4 and SW4-5 set to ON), full cutting is used for
paper regardless of the setting of memory switch SW4-8.
*4: When printing on label paper, printing columns of 660 dots is not usable.
Memory switch SW2-8 is not usable with label paper.
— 29 —
