4. Rear brake lock lever
Rear brake lock is useful when your scooter is parked with
side stand on a slope to avoid falling.
To apply the rear brake lock, squeeze the rear brake lever
fully towards the grip as much required, by holding it as it is
press and hold the brake lock lever. Now release the brake
lever and ensure the brake is locked properly.
To release the rear brake lock, squeeze the rear brake lever
further in and the lock will release automatically, then
release the brake lever.
5. High/low beam cum pass by switch
With the head lamp switch in ‘ON’ condition, press the
1
2
3
5
4
Always use the appropriate turn signal lamps when you intend to
change lanes or take turns. Be sure to switch ‘OFF’ the turn signal
lamps after negotiating the lanes or turns.
KNOW YOUR TVS JUPITER
high/low beam switch towards ‘ ’ to operate the head
lamp high beam and towards ‘ ’ to operate the head lamp
low beam.
WARNING
19
KNOW YOUR TVS JUPITER
TVS JUPITER has a combined switch for head lamp high/low
beam and pass by. To operate the pass by, keep the switch in
‘low beam’ position, press gently and release. This makes
the head lamp high beam to flash and signal the
approaching vehicle. The pass by signal can be used while
overtaking during day time.
Use appropriate head lamp beam high/low as per the traffic and
road conditions for your safety and to avoid inconvenience to other
riders.
WARNING
HANDLE BAR RIGHT SIDE
1. Front brake lever
The front brake is applied by squeezing the front brake lever
gently towards the throttle grip. The brake lamp glows on
application of front brake.
