CHASSIS
Dimensions and weight
Frame : Duplex tubular frame
Front suspension : Telescopic hydraulic
Rear suspension : Toggle link, gas filled hydraulic
damper
Trail length : 93 mm
TYRE
Front tyre : 90/90 x 12 (tubeless)
Rear tyre : 90/90 x 12 (tubeless)
Tyre pressure (cold condition)
Front : 1.69 kg/cm2 (24 PSI)
Rear - Solo : 2.00 kg/cm2 (28 PSI)
Rear - Pillion : 2.25 kg/cm2 (32 PSI)
BRAKES
Front : 130 mm dia (hand operated)
Rear : 130 mm dia (hand operated)
ELECTRICAL
Ignition system : IDI ignition
ELECTRICAL
Spark plug : Bosch UR4KC
Spark plug gap : 0.9 ~ 1.0 mm
Battery : 12V, 5Ah Lead Acid type
Generator : Fly wheel magneto, 12V, 80W
Head lamp : Halogen HS 12V, 35/35W
Tail / brake lamp : 12V, LED
Turn signal lamps : 12V, 10W x 4
Position lamp : 12V, 3W x 2
Number plate lamp : 12V, 4W x 1
Speedometer lamp : 12V, 1.7W x 2
Turn signal indicator lamp : 12V, 1.7W x 2
Low fuel warning lamp : 12V, LED
High beam indicator lamp : 12V, 1.7W x 1
Economy and power
mode indicator lamp : 12V, LED
Horn : 12V, DC
Fuse : 12V, 10A x 1 (Blade type)
Using the bulb other than the specified rating can result in
overloading the electrical system or premature failure of the bulb.
CAUTION
TECHNICAL SPECIFICATION
TECHNICAL SPECIFICATIONS
