ENGINE OIL LEVEL
Check the engine oil level periodically.
1. Place the vehicle on centre stand on a flat surface. Wipe-
off the surroundings of gauge oil level.
2. Remove the gauge and wipe it clean.
3. Fix the gauge back to its mounting hole. Do not thread
in.
4. Take out the gauge and check the oil level. The level
should be between minimum and maximum level marks
of the gauge (shown in the figure).
5. If the oil is less than the minimum level, add 4T oil upto
the maximum level mark.
6. Wipe out the oil traces with a clean cloth to prevent dust
accumulation.
7. Assemble back the gauge oil level.
TRANSMISSION OIL - LEVEL
Check the transmission oil level periodically.
1. Place the vehicle on centre stand on a flat surface. Wipe-
off the surroundings of oil level bolt.
2. Remove the transmission oil level bolt along with a
gasket from the rear end of crankcase L.
3. Check for the flow of oil from oil level hole.
Maximum
Minimum
MAINTENANCE
MAINTENANCE
39
