60
CHASSIS
Overall length : 2025 mm
Overall width : 705 mm
Overall height : 1080 mm
Ground clearance : 180 mm (unladen)
Wheel base : 1265 mm
Kerb weight : 116 kg (Front Drum Brake version)
(with tool kit & 90% of fuel) : 118 kg (Front Disc Brake version)
Pay load : 130 kg
Maximum laden weight : 246 kg (Front Drum Brake version)
: 248 kg (Front Disc Brake version)
Steering angle : 88°
Caster angle : 26°
Frame : Single cradle tubular frame
Front suspension : Telescopic oil damped
Rear suspension : 5 step adjustable hydraulic
shocks with swing arm
Trail length : 83 mm
TYRE
Front tyre : 2.75 - 18 42P 4PR (tubeless)
Rear tyre : 3.00 - 18 52P 6PR (tubeless)
Tyre pressure
Front : 1.75 kg/cm
2
(25 PSI)
Rear - Solo : 2.25 kg/cm
2
(32 PSI)
Rear - Pillion : 2.50 kg/cm
2
(36 PSI)
ELECTRICAL
Ignition system : ECU - Electronic Control Unit
Spark plug : BOSCH UR5KCW
Spark plug gap : 0.9 ~ 1.0 mm
Magneto : 12V, 160W (fly wheel magneto)
Battery : 12V, 4 Ah
Maintenance free battery
Head lamp bulb : 12V, HS1 35/35W x 1
DRL lamps : 12V, LED 5W
Tail / brake lamp bulb : 12V, 5/21W x 1
Turn signal lamps bulb : 12V, 10W x 4
Speedometer lamp bulb : 12V, 3.4W x 2
Using the bulb other than the specified rating can result in
overloading of the electrical system or premature failure
of the bulb.
