Jumpers & Connectors
Jumper/Connector Function
Rear Fan/CPU Fan/Front Fan 4-pin Fan Connector
SATA_6G_0/SATA_6G_1 SATA3.0 Connector
SATA2/SATA3/SATA4/SATA5 SATA2.0 Connector
COM1/COM2/COM3/COM4 COM Port Header
J35 APS Header
J2 ID LED Switch Header
J20 Front Panel Header
J82 FP 82579 LAN Activity LED Header
J76 FP 82583 LAN Activity LED Header
INT_SPKR Internal Speaker Header
J4 CMOS Clear Jumper
F_AUDIO1 Front Audio Connector
U_SPI1 BIOS SPI ROM Header
FCFH1 Chassis Intrusion Header
J81 SATA DOM 2-pin Header
J6 ME Header
J13 SPDIF Header
J83 Speaker Header
FP_USB1/2 Front USB Connector
LED1 ID LED
AUX_Power_LED1 Aux Power LED 3-pin Header
USB_A Type-A USB Connector
Jumper Legend
OPEN - Jumper OFF
Without jumper cover
CLOSED - Jumper ON
With jumper cover
