Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN
®
S5515 motherboard, based on the
Intel
®
Q67 and Nuvoton NCT5577D chipsets. The S5515 is designed to support
single Intel
®
Core i3/i5/i7 series processor, and up to 32GB of un-buffered non-
ECC 1066/1333MHz DDR3 memory. Leveraging advanced technology from
Intel
®
, the S5515 is capable of offering scalable 32 and 64-bit computing, high-
bandwidth memory design, and lightning-fast PCI-E bus implementation.
The S5515 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provides the S5515 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN
®
website at http://www.tyan.com. There you can
find all the information on all TYAN
®
products as well as all the supporting
documentation, FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
TYAN S5515 (S5515AG2NR)
Supported CPU
Series
Intel Core i3/ i5/ i7 32nm / 22nm series processor
Socket Type / Q'ty LGA 1155/ (1)
Processor
Thermal Design
Power (TDP)
wattage
Max up to 95W
PCH Intel Q67
Chipset
Super I/O Nuvoton 5577D
Supported DIMM
Qty
(4) DIMM slots
DIMM Type / Speed
Unbuffered Non-ECC DDR3 / 1600*/1333/1066
*22nm Ivy bridge Support
Capacity Up to 32GB
Memory channel 2 Channels
Memory
Memory voltage 1.5V
PCI-E
(1) PCI-E Gen.2 x1 slot / (1) PCI-E Gen.2 x8 slot (w/
x4 link) / (1) PCI-E Gen.2/Gen.3 x16 slot
Note: use Intel Ivy Bridge CPU to support PCI-E Gen.3
Expansion
Slots
PCI (1) PCI 32-bit slot (5V)
