6
Port Q'ty (2)
Controller Intel 82583
LAN
PHY Intel 82579
Connector (6) SATA
Controller Intel Q67
Speed (2) 6.0 Gb/s (blue color), (4) 3.0 Gb/s (black color)
Storage SATA
RAID RAID 0/1/10/5 (Intel RST)
Connector type
D-Sub 15-pin / DVI-D / Display port 1.1 / Only two
video outputs at the same time
Resolution Up to 1920x1024
Graphic
Chipset Intel Q67
Chipset Realtek ALC888
Audio
Feature High Definition Audio
USB
(9) USB2.0 ports (4 at rear, 4 via cable, 1 type A
onboard), (2) USB3.0 ports (NEC, uPD720200)
COM (4) headers
VGA (1) D-Sub 15-pin VGA port / (1) Display port 1.1
DVI (1) DVI-D connector
Audio LINE_IN, LINE_OUT, MIC_IN connectors
RJ-45 (2) GbE ports
Power SSI/ATX 24-pin + 4-pin power connectors
Front Panel (1) 2x12-pin SSI front panel header
Input /Output
SATA (4) SATA-II and (2) SATA-III connectors
Chipset Nuvoton 5577D
Voltage
Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (3) 4-pin headers
System
Monitoring
Temperature Monitors temperature for CPU & system environment
Brand / ROM size AMI / 8MB
BIOS
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/PXE boot / ACPI 2.0 power management /Power on
mode after power recovery / User-configurable H/W
monitoring / Auto-configurable of hard disk types
Form Factor Micro ATX
Physical
Dimension
Board Dimension 9.6"x9.6" (243.8x243.8mm)
Operating
System
OS supported list Please visit our Web site for the latest update.
FCC (DoC) Class B
Regulation
CE (DoC) Yes
