Recommended Memory Population Table
Single CPU Installed
Quantity of memory installed 1 2 3 4
DIMM1 √ √ √
DIMM2 √ √ √ √
DIMM3 √
DIMM4 √ √
NOTE:
1. √ indicates a populated DIMM slot.
2. Paired memory installation for Max performance.
3. Populate the same DIMM type in each channel, specifically
- Use the same DIMM size
- Use the same # of ranks per DIMM
4. Dual-rank DIMMs are recommended over single-rank DIMMs
5. Un-buffered DIMM can offer slightly better performance than registerd DIMM if
only a single DIMM per channel populated
6. We don't suggest other memory installation.
U-DIMM Module Support
DDR3 Speed/Voltage DDR3 Rank Configuration
1.5v (DIMM1, DIMM2) (DIMM3, DIMM4)
1066MHz SR and DR
1066MHz SR and DR SR and DR
1333MHz SR and DR
1333MHz SR and DR SR and DR
1600MHz SR and DR
1600MHz SR and DR SR and DR
NOTES:
 UDIMM can support up to 8GB sized DIMM’s
 Maximum of 16GB per channel
 SR and DR UDDR3 module support only

SR and DR 1.5v Memory MAX speed of 1333/1600* MHz in a dual channel
configuration
*
IVB CPU can support up to 1600MHz.
