53
3.3.9.1 Console Redirection Settings
Aptio Setup Utility --- Copyright © 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Emulation: ANSI: Extended
ASCII char. set. VT100:
ASCII char. set. VT100+:
Extends VT100 to support
color, function keys etc. VT-
UTF8: uses UTF8 encoding
to map Unicode chars onto 1
or more bytes.
COM1
Console Redirection Settings
Terminal Type
Bits per Second
Data Bits
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Legacy OS Redirection Resolution
Putty KeyPad
[ANSI]
[115200]
[8]
[None]
[1]
[None]
[Enabled]
[Disabled]
[Disabled]
[80x24]
[VT100]
→←: Select screen
↑↓: Select item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Terminal Type
Emulation: ANSI: Extended ASCII char. set. VT100: ASCII char. set. VT100+:
Extends VT100 to support color, function keys etc. VT-UTF8: uses UTF8 encoding
to map Unicode chars onto 1 or more bytes.
ANSI / VT-UTF8 / VT100 / VT100+
Bits per Second
Select serial port transmission speed. The speed must be matched on the other
side. Long or noisy lines may require lower speeds.
115200 / 57600 / 38400 / 19200 / 9600
Data Bits
Data Bits.
8 / 7
Parity
A parity bit can be sent with the data bits to detect some transmission errors. Even:
parity bit is 0 if the num of 1’s in the data bits is even. Odd: parity bit is 0 if the num
of 1’s in the data bits is odd. Mark: parity bit is always 1. Space: parity bit is always
0. Mark and Space parity do not allow for error detection.
None / Even / Odd / Mark / Space
