3.3.9.2 Serial Port for Out-Of-Band Management/Windows Emergency
Services (EMS) Console Redirection Settings
Aptio Setup Utility --- Copyright © 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Microsoft Windows Emergency
Management Services (EMS)
allows for remote management of
a Windows Server OS through a
serial port.
Out-of-Band Mgmt Port
Terminal Type
Bits per Second
Flow Control
Data Bits
Parity
Stop Bits
[COM1]
[VT-UTF8]
[115200]
[None]
8
None
1
→←: Select screen
↑↓: Select item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Out-of-Band Mgmt Port
Microsoft Windows Emergency Management Services (EMS) allows for remote
management of a Windows Server OS through a serial port.
COM1 / COM2 / COM3 / COM4
Terminal Type
VT-UTF8 is the preferred terminal type for out-of-band management. The next best
choice is VT100+ and then VT100. See above, in Console Redirection Settings
page, for more Help with Terminal Type/Emulation.
VT-UTF8 / VT100 / VT100+ / ANSI
Bits per Second
Select serial port transmission speed. The speed must be matched on the other
side. Long or noisy lines may require lower speeds.
115200 / 9600 / 19200 / 57600
Flow Control
Flow Control can prevent data loss from buffer overflow. When sending data, if the
receiving buffers are full, a ‘stop’ signal can be sent to stop the data flow. Once the
buffers are empty, a ‘start’ signal can be sent to restart the flow. Hardware flow
control uses two wires to send start/stop signal.
None / Hardware RTS/CTS / Software Xon/Xoff
Data Bits / Parity / Stop Bits
Read only.
