3.4.1 South Bridge
Aptio Setup Utility --- Copyright © 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Configure the DeepSx Mode
Configuration. WOL wake up
function would not usable
when users enable Sx
function.
DeepSx Power Policies
High Precision Event Timer Configuration
High Precision Timer
SLP_S4 Assertion Width
Restore AC Power Loss
Chassis Intrusion Detection
[Disabled]
[Enabled]
[4-5 Seconds]
[Power Off]
[Disabled]
→←: Select screen
↑↓: Select item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
DeepSx Power Policies
Configure the DeepSx Mode Configuration. WOL wake up function would not
usable when users enable Sx function. Note : Mobile platforms support Deep S4/S5
in DC only and Desktop platforms support Deep S4/S5 in AC only.
Disabled / Enabled in S5 / Enabled in S4-S5
High Precision Timer
Enable or disable the High Precision Event Timer.
Enabled / Disabled
SLP_S4 Assertion Width
Select a minimum assertion width of the SLP_S4# signal.
4-5 Seconds / 1-2 Seconds / 2-3 Seconds / 3-4 Seconds / Disabled
Restore AC Power Loss
Select AC power state when power is re-applied after a power failure.
Power Off / Power On / Last State
Chassis Intrusion Detection
Enabled: When a chassis open event is detected, the BIOS will display the event.
Disabled / Enabled
