132
3.4.4.2 Memory RAS Configuration
Dynamic ECC Mode Selection
Enabled/Disabled Dynamic ECC Mode selection
Disabled / Enabled
Mirror Mode
Full Mirror mode will set entire 1LM memory in system to be mirrored , consequently
reducing the memory capacity by half. Partial Mirror Mode will enable the required
size of memory to be mirrored. If rank sparing is enabled partial mirroring will not
take effect. Enabling any type of Mirror Mode will disable.
Disabled / Enabled
Mirror TAD0
Enabled Mirror on entire memory for TAD0
Disabled / Enabled
Correctable Error Threshold
Correctable Error Threshold (1-32767) used for sparing, and leaky bucket.
10
