Appendix III: PCIE Bus Number
If PCIE#3 is not inserted, only PCIE#1, #2, #4, and #5 are inserted, check the table
below for the PCIE Bus Number and its corresponding PCIE Slot.

 PCIE#1 PCIE#2 PCIE#3 PCIE#4 PCIE#5
CPUIOU 4A 1A 5G 2A 3A
PE PE3 PE0 PE4 PE1 PE2
PCIeBusNumber 94h 16h X 40h 6Ah
