Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN
®
S5652 motherboard, based on the Intel
®
C741 chipset. The S5652 is designed to support Single 4th Gen. Intel Xeon
Scalable Processor / 5th Gen. Intel Xeon Scalable Processor, and up to 1,024GB
RDIMM/2,048GB 3DS RDIMM 5600/4800/4400 DDR5 memory. Leveraging
advanced technology from Intel
®
, the S5652 is capable of offering scalable 64-bit
computing, high-bandwidth memory design, and lightning-fast PCI-E bus
implementation.
The S5652 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provide the S5652 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN
®
website at http://www.tyan.com. There you can find
all the information on all TYAN
®
products as well as all the supporting documentation,
FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
S5652AGMNRE Specifications
Processor
Q'ty / Socket Type (1) LGA4677
Supported CPU Series 4th Gen. Intel Xeon Scalable Processors / 5th
Gen. Intel Xeon Scalable Processors
Thermal Design Power
Wattage
Max up to 350W (TDP)
Chipset PCH Intel C741
Memory
Supported DIMM Qty (8) DIMM slots
DIMM Type / Speed DDR5 4800 MHz (1DPC) / 4400MHz (2DPC) -
4th Gen. / DDR5 5600 MHz (1DPC) / 4400MHz
(2DPC) - 5th Gen.
Capacity Up to 1,024GB RDIMM/2,048GB 3DS RDIMM
5600/4800/4400 memory *Follow latest Intel
DDR5 Memory POR
Memory channel 8 Channels per CPU
Memory voltage 1.1V
Expansion Slots PCIe (1) PCIe Gen.5 x8 slot / (4) PCIe Gen.5 x16 slot
LAN
Q'ty / Port (1) GbE port + (1) GbE dedicated for IPMI
Controller Intel I210
PHY Realtek RTL8211F
Storage SATA
Connector (1) Mini SAS-HD connector + (2) SATA-III
connectors
