2.13 Connecting External Devices
Connecting external devices to the motherboard is an easy task. The motherboard
supports a number of different interfaces through connecting peripherals. See the
following diagrams for the details.
S5652AGM3NRE-2T
S5652AGMNRE
COM1 Port
ID_Button
VGA Port
USB3.2Gen1 x2
USB2.0 x 2
Audio Jack
LAN4
LAN1
COM1 Port
ID_Button
VGA Port
USB3.2Gen1 x 2
USB2.0 x 2
Audio Jack
LAN2
LAN3
Dedicate to IPMI
LAN1
Dedicate to IPMI
LAN2
