3.6 Server Management
FRB-2 Timer
Enable or Disable FRB-2 timer (POST timer).
Enabled / Disabled
NOTE: When FRB-2 Timer was set to Enabled, the following 3 items will be
available.
FRB-2 Timer timeout
Enter value Between 3 to 6 min for FRB-2 Timer Expiration value.
3 minutes / 4 minutes / 5 minutes / 6 minutes / 12 minutes
FRB-2 Timer Policy
Configure how the system should respond if the FRB-2 Timer expires. Not available
if FRB-2 Timer is disabled.
Do Nothing / Reset / Power Down / Power Cycle
OS Watchdog Timer
If enabled, starts a BIOS timer which can only be shut off by Management Software
after the OS loads. Helps determine that the OS successfully loaded or follows the
OS Boot Watchdog Timer policy.
Enabled / Disabled
