TYAN S5652 - Software Specifications

http://www.tyan.com
9
BIOS
Brand / ROM size AMI / 32MB
Feature Hardware Monitor / Boot from USB device/PXE
via LAN/Storage / User Configurable FAN PWM
Duty Cycle / SMBIOS 3.3/PnP/Wake on LAN /
ACPI sleeping states S0, S5
Physical
Dimension
Form Factor SSI CEB compatible
Board Dimension 12” x 10.5” (305 x 267mm)
Regulation
FCC (SDoC) Class B
CE (DoC) Class B
RCM Class B
VCCI Class B
Operating
Environment
Operating Temp. 0° C ~ 40° C (32° F~ 104° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Operating
System
OS supported list Please refer to our AVL support lists.
Package
Contains
Motherboard (1) S5652 Motherboard
Manual (1) Quick Installation Guide
I/O Shield (1) I/O Shield
Cable SATA (2) SATA signal cables
1.3 Software Specifications
For the latest AST2600 User’s Guide and OS (operation system) support, please
visit the Tyan’s Web site at http://www.tyan.com for the latest information
