8
connectors
Controller Intel C741
Speed 6Gb/s
RAID RAID 0/1/10/5 (Intel RSTe)
Storage NVMe
Connector (M.2) (1) 2280 (by PCIe 4 interface)
Connector (U.2) (1) MCIO x8
Storage
(Optional)
VROC Support Yes
Graphic VGA
Connector type D-Sub 15-pin
Resolution Up to 1920x1200 @60Hz
Chipset Aspeed AST2600
Input /Output
USB (1) USB2.0 port ( Type-A ) / (2) USB2.0 ports (@
rear) / (2) USB3.2 Gen.1 ports ( @ rear)
COM (1) COM port header + (1) DB-9 COM Connector
(@rear)
VGA (1) D-Sub 15-pin VGA port (@ rear)
RJ-45 (2) 10GbE ports + (1) GbE ports +
(1) GbE dedicated for IPMI
Front Panel (1) 2x12-pin SSI front panel header(mini type)
Audio (1) 2x5-pin header / (1) 3 holes Audio Jack
connector
SATA (1) Mini SAS-HD connector + (2) SATA-III
connectors
Power 8-pin power connectors
Others (1) UID button
TPM (Optional)
TPM Support Please refer to our TPM supported list.
Interface SPI
System
Monitoring
Chipset Aspeed AST2600
Fan Total (6) 4-pin headers
Temperature Monitors temperature for CPU, memory & system
environment
Voltage Monitors voltage for CPU, memory, chipset &
power supply
LED Over temperature warning indicator /
Fan & PSU fail LED indicator
Others Watchdog timer support
Audio
Chipset Realtek ALC888S
Feature 2.1 ch
Server
Management
Onboard Chipset Onboard Aspeed AST2600
AST2600 iKVM Feature 24-bit high quality video compression / Supports
storage over IP and remote platform-flash / USB
2.0 virtual hub
AST2600 IPMI Feature IPMI 2.0 compliant baseboard management
controller (BMC) / 10/100/1000 Mb/s MAC
interface
