7
Feature Hardware Monitor / Boot from USB device/PXE
via LAN/Storage / User Configurable FAN PWM
Duty Cycle / SMBIOS 3.3/PnP/Wake on LAN /
ACPI sleeping states S0, S5
Physical
Dimension
Form Factor SSI CEB compatible
Board Dimension 12” x 10.5” (305 x 267mm)
Regulation
FCC (SDoC) Class B
CE (DoC) Class B
RCM Class B
VCCI Class B
Operating
Environment
Operating Temp. 0° C ~ 40° C (32° F~ 104° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Operating
System
OS supported list Please refer to our AVL support lists.
Package
Contains
Motherboard (1) S5652 Motherboard
Manual (1) Quick Installation Guide
I/O Shield (1) I/O Shield
Cable SATA (2) SATA signal cables
S5652AGM3NRE-2T Specifications
Processor
Q'ty / Socket Type (1) LGA4677
Supported CPU Series 4th Gen. Intel Xeon Scalable Processors / 5th
Gen. Intel Xeon Scalable Processors
Thermal Design Power
Wattage
Max up to 350W (TDP)
Chipset PCH Intel C741
Memory
Supported DIMM Qty (8) DIMM slots
DIMM Type / Speed RDDR5 4800 w/ ECC (1.1V) when 2DPC/1DPC /
LRDDR5 4800 w/ ECC (1.1V) when 2DPC/1DPC
Capacity Up to 1,024GB RDIMM/ 2,048GB LRDIMM/
2,048GB RDIMM 3DS/LRDIMM 3DS *Follow
latest Intel DDR5 Memory POR
Memory channel 8 Channels per CPU
Memory voltage 1.1V
Expansion Slots PCIe (1) PCIe Gen.5 x8 slot / (4) PCIe Gen.5 x16 slot
LAN
Q'ty / Port (2) 10GbE ports + (1) GbE ports + (1) GbE
dedicated for IPMI
Controller Intel I210 / Intel X550
PHY Realtek RTL8211F
Storage SATA Connector (1) Mini SAS-HD connector + (2) SATA-III
