BIOS Temp Sensor Name Explanation
P0_Temp P0 Temperature
PCH_Temp Temperature of PCH
P0_CHA_DIM0 Temperature of CPU0 DIMM Channel A
P0_CHB_DIM0 Temperature of CPU0 DIMM Channel B
P0_CHC_DIM0 Temperature of CPU0 DIMM Channel C
P0_CHD_DIM0 Temperature of CPU0 DIMM Channel D
P0_CHE_DIM0 Temperature of CPU0 DIMM Channel E
P0_CHF_DIM0 Temperature of CPU0 DIMM Channel F
P0_CHG_DIM0 Temperature of CPU0 DIMM Channel G
P0_CHH_DIM0 Temperature of CPU0 DIMM Channel H
SYS_Air_Inlet Temperature of the System Air Inlet Area
SYS_Air_Outlet Temperature of the System Air Outlet Area
U.2_NVME_SSD_0 Temperature of the U.2_NVME_SSD_0
U.2_NVME_SSD_1 Temperature of the U.2_NVME_SSD_1
M.2_NVME_SSD_0 Temperature of the M.2_NVME_SSD_0
CPU_FAN Fan Speed of CPU_FAN
SYS_FAN_1 Fan Speed of SYS_FAN_1
SYS_FAN_2 Fan Speed of SYS_FAN_2
SYS_FAN_3 Fan Speed of SYS_FAN_3
SYS_FAN_4 Fan Speed of SYS_FAN_4
SYS_FAN_5 Fan Speed of SYS_FAN_5
SYS_FAN_6 Fan Speed of SYS_FAN_6
SYS_FAN_7 Fan Speed of SYS_FAN_7
