11
Form Factor SSI CEB
Form Factor
Board
Dimension
12"x10.5" (305x267mm)
Operation System
OS supported
list
Please refer to our OS supported list.
FCC (Doc) Class B
Regulation
CE (Doc) Yes
Operating Temp 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp
- 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-
operating
Humidity
90%, non-condensing at 35° C
RoHS
RoHS 6/6
Complaint
Yes
Motherboard (1) TYAN motherboard
Manual (1) User's manual / (1) Quick Ref. Guide
Installation CD (1) TYAN Installation CD
I/O Shield (1) I/O Shield
Accessory list
Cable (6) SATA signal cables
Riser Card M2083-RS, PCI-E 1U riser card (left)
Optional
accessories for
future upgrade
Cable
(1) CCBL-0615, COM port cable / (1) SAS cable
for S7002 / (1) CCBL-0311, SATA 1-to-2 power
cable / (1) CCBL-035J, USB bracket cable
TYAN S7002-LE (S7002WGM2NR-LE)
Supported CPU Series Intel Xeon 5500 series QC/DC processors
Socket Type / QTY LGA1366 / (2)
Thermal Design Power (TDP)
wattage
130W
Processor
System Bus (MHz) 1333/1066/800
IOH / ICH Intel 5500 / ICH10R
Chipset
Super I/O Winbond W83627
Memory
Supported DIMM Qty (8) DIMM sockets
