12
DIMM Type / Speed DDR3 800/1066/1333 RDIMM, UDIMM
Capacity Up to 64GB
Memory channel 6 channels (3-channel per CPU)
Memory
Memory voltage 1.5V
PCI-E
(1) PCI-E x16 slot (Gen 2) / (2) PCI-E x8 slots (w/
x4 link)
Expansion
Slots
Recommended TYAN
Riser Card
M2083-RS, PCI-E x16 1U riser card (left)
Port QTY (2)
LAN
Controller Intel 82574
Connector (8)
Controller LSI SAS1068E
Speed 3.0 Gb/s
SAS
RAID S/W RAID 0,1,1E standard
Connector (6)
Controller ICH10R
Speed 3.0 Gb/s
Storage
SATA
RAID S/W RAID 0,1,5,10 standard
Connector type D-Sub 15pin (Embedded VGA)
Resolution 1600x1200@60Hz
Graphic
Chipset Aspeed AST2050
USB (8) USB2.0 ports (4 at rear, 4 via cable)
COM (2) ports (1 at rear, 1 via cable)
SAS (8) SAS connectors
VGA (1) D-Sub 15pin VGA port(Embedded VGA)
RJ-45 (2) GbE ports
Power
SSI 24-pin + 8-pin + 8-pin power connectors /
EPS-12V
Front Panel (1) 2x12 pin SSI Front Panel header
Input /Output
SATA (6) SATAII connectors
Chipset Winbond W83793G
Voltage
Monitors voltage for CPU, memory, chipset &
power supply
System
Monitoring
Fan Total (5) 4-pin headers
