14
Riser
Card
M2083-RS, PCI-E 1U riser card (left)
Optional accessories
for future upgrade
Cable
(1) CCBL-0615, COM port cable / (1) SAS cable for
S7002 / (1) CCBL-0311, SATA 1-to-2 power cable / (1)
CCBL-035J, USB bracket cable
TYAN S7002-LE (S7002GM2NR-LE)
Supported CPU Series
Intel Xeon 5500 series
QC/DC processors
Socket Type / QTY LGA1366 / (2)
Thermal Design Power (TDP) wattage
130W
Processor
System Bus (MHz) 1333/1066/800
IOH / ICH Intel 5500 / ICH10R
Chipset
Super I/O Winbond W83627
Supported DIMM Qty (8) DIMM sockets
DIMM Type / Speed
DDR3 800/1066/1333
RDIMM, UDIMM
Capacity Up to 64GB
Memory channel
6 channels (3-channel per
CPU)
Memory
Memory voltage 1.5V
PCI-E
(1) PCI-E x16 slot (Gen 2) /
(2) PCI-E x8 slots (w/ x4
link)
Expansion Slots
Recommended TYAN Riser Card
M2083-RS, PCI-E x16 1U
riser card (left)
Recommended
Barebone /
Chassis
1U Barebone GT20-B7002
Port QTY (2)
LAN
Controller Intel 82574
Connector (6)
Controller ICH10R
Speed 3.0 Gb/s
Storage SATA
RAID S/W RAID 0,1,5,10
